This Centerforce Twin Disc clutch offers smooth engagement, quiet operation, light pedal, and high-end holding capacity.
Available for Dodge Cummins Diesel equipped 2500-5500 trucks. Centerforce announces their NEW Twin Disc clutch set for Heavy-Duty street and towing use. Truck owners pushing power levels up to 1700 ft/lbs will enjoy the smooth and quiet operation this unique clutch set offers. All components are match balanced and ready for installation.
Application Summary:
| Year |
Make/Model |
| 2005-2010 |
Dodge Ram 2500 |
| 2005-2010 |
Dodge Ram 3500 |
| 2008-2010 |
Dodge Ram 4500 |
| 2008-2010 |
Dodge Ram 5500 |
| 2011-2018 |
Ram 2500 |
| 2011-2018 |
Ram 3500 |
| 2011-2017 |
Ram 4500 |
| 2011-2016 |
Ram 5500 |
| Attributes |
| Alignment Tool Included |
Yes, Yes |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Clutch Bolt Pattern |
22, 22 |
| Clutch Disc Diameter |
12.250, 12.250, 311.2 |
| Counterweight Assist |
YES, Yes |
| Country of Origin (Primary) |
US |
| Crankshaft Bolt Hole Quantity |
8, 8, 8 |
| Disc Material |
Organic/Carbon composite, Organic/Carbon composite |
| Disc Type |
Segmented face, Segmented face |
| Disc Type Sprung Solid |
Sprung, Sprung, Sprung |
| Emission Code |
Legal US |
| Flywheel Crank Bolt Size |
M12 x 1.25 x 32, 12mm, M12 x 1.25 x 32 |
| Flywheel Crank Flange Register |
5.118, 5.118 |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Input Shaft Diameter |
1-3/8, 1-3/8 |
| Input Spline Quantity |
10, 10 |
| Installed Height |
4.475, 4.475 |
| Life Cycle Status Code |
Available to Order |
| Made In The USA |
Assembled, Assembled |
| Material |
Billet Steel Flywheel / Cast Iron Pressure Plate / Segmented Organic Friction, Billet Steel Flywheel / Cast Iron Pressure Plate / Segmented Organic Friction |
| Mounting Hardware Included |
Yes, Yes |
| NAFTA Preference Criterion Code |
B |
| Out of Package Weight |
109.10 |
| Outside Diameter |
15.625 |
| Pilot Bushing Included |
Yes, Yes |
| Pilot Bushing Material |
Bearing, Bearing |
| Release Bearing Included |
Yes, Yes |
| Release Bearing Style |
Flat Face, Flat Face |
| Ring Gear O.D |
15.625 |
| Ring Gear O.D. |
15.625, 15.625 |
| Ring Gear OD |
15.625 |
| Ring Gear Tooth Count |
152 |
| SDR Required Flag |
N |
| Tooth Quantity |
152, 152 |
| Torque Capacity |
1700, 1700 |
| Warranty Time |
12 |
| GTIN |
00788442033779 |
